ST-S555ESUS ModelCanadian ModelAEP ModelFM STEREO TUNERSPECIFICATIONSGeneralSystemPLL quartz-locked digital synthesizersystemPower requirementsAEP model:220 V ac (or 240 V ac adjustable byauthorized Sony personnel),50/60 HzUS,Canadian model:120 V ac,60 HzPower consumptionAEP model:25 wattsUS,Canadian model:23 wattsDimensionsApprox.430x80x340mm{w/h/d)(17×3%x13 inches)0dB=0.775Vincluding projecting parts and controlsContinued on page 2-WeightAEP model:Approx.4.9 kg (10 lbs 13 oz)netApprox.5.9 kg (13 Ibs 1 oz)inATTENTION AU COMPOSANT AYANT RAPPORTshipping cartonA LA SECURITE!US,Canadian model:LES COMPOSANTS IDENTIFIES PAR UNE TRAME ETApprox.4.8 kg (10 Ibs 10 oz)netUNE MARQUE SUR LES DIAGRAMMES SCHEApprox.5.8 kg (12 Ibs 13 oz)inMATIQUES ET LA LISTE DES PIECES SONT CRITIQUESshipping cartonPOUR LA SECURITE DE FONCTIONNEMENT.NE REMPLACER CES COMPOSANTS QUE PAR DES PIECESSONY DONT LES NUMEROS SONT DONNES DANS CEMANUEL OU DANS LES SUPPLEMENTS PUBLIES PARSONYSAFETY-RELATED COMPONENT WARNING!COMPONENTS IDENTIFIED BY SHADING AND MARKON THE SCHEMATIC DIAGRAMS AND IN THESONYPARTS LIST ARE CRITICAL TO SAFE OPERATIONREPLACE THESE COMPONENTS WITH SONY PARTSWHOSE PART NUMBERS APPEAR AS SHOWN IN THISMICROFILMSERVICE MANUALMANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY
