Technical data on the vehicleMakeIveco LVDate:06-07-2011ModelStralis 440 E 44 Cursor 13OwnerYear2002-2009Registration No.EngineF3B E0681CVINVariant1.Reg.DateTechnical itemDataEngineEngine ID codeF3B E0681CNumber of cylindersR6Number of valves24,OHVCapacity/(bore/stroke)12880cm3(135,0/1500)Compression ratio16,5:1Max.output kW (din hp)/rpm324(440)/1450-1900Max.torque NM/rpm2100/1000-1470Engine code locationEngine block left sideVehicle Identification Number locationRight side rail by front wheelVehicle identification plate locationBehind front grilleValve clearance,inlet (cold/hot)0.40±0.05codValve clearance,exhaust (cold/hot)0.60±0.05coldValve angle/seat angleIntake60°30'/60°Exhaust45°30'/45°Valve height in cylinder head,mmOil pressure/rpm,barMin.1.5/idle speed (5.0/max.rpm)Radiator cap,bar/thermostat C/84°±2°CThermostat gap at test temperatureMaX.open/94°±2°CClutch freeplay,mm(Hydraulic)Timing gear:Drive beltEnqine manaqementEngine management systemBosch MS6.2 PDEPump/pump typeBosch/PDE 31Injector/injector typeBosch/Crank position engine piston,mmE目lectronicPump position,mmAdiustment methodInjector opening pressure,new,bar1500Injection order1-4-2-6-3-5Electrical systemTerminal definitions DIN 72 552Wheel alignmentLoadUnloadedToe-in,mm1,00±0,75Cambero1°Castero1°24KPI/SAI70Rear cambero10Rear toe-inoLeft wheel0±0.75/Right wheel÷2.00±0.75Tightening torquesTightening,NMTorque standardsCylinder head bolts,stage 1,Nm60 Nm oiledCylinder head bolts,stage 2,Nm120NmCylinder head bolts,stage 3.Nm+90°Cylinder head bolts,stage 4,NmBolts4,5,12,20,21=45oCylinder head bolts,stage 5,NmOthers =65Main bearings,Nm
