SC-5300/533SERVICE MANUALSPECIFICATIONSTrack.4-Track(2-Channel Stereo)Tape speed.......4.8cm/ec.(1-7/8ips)HeadsRecord/Playback:FH HeadErase:Double Gap Ferrite HeadSTEREO CASSETTE TAPE DECKMotorCapstan:FG Servo DC MotorReels:DC MotorWow and flutterwithin 0.038%WRMSFast wind time.approximately 70 seconds(C-60)SANSUI SC-5300Frequency response(Record/Playback)Normal Tape(LH)(-20VU)20to17,000HzSC-5330(20to15,000Hz±3dB)Metal Tape (-20 VU)20to21,000Hz(20to20,000Hz±3dB)(0 VU).20 to 15,000 Hz +3 dBSignal to nolse ratio (Record/Playback)Metal Tape(without Dolby Noise Reddction Effect)....better than 59 dB(weighted)(With Dolby Noise Reduction).....better than 69 dB (above 5 kHz)Erasure factor (Metal Tape)..more than 70 dB at 1,000 HzInput sensitivity and impedance(0 VU,1,000 Hz)MIC...0.2mV/200n-5knLINE IN (REC)..70 mV/33 knOutput level (0 VU,1,000 Hz)LINE OUT(PLAY)回··400mVPHONES .....100 mV/82Bias frequency,·,··85 kHzPower requirementsPower voltage....100,120,220,240 V(50/60Hz)For U.S.A.and Canada120V(60Hz)Power consumption…·.,,35w(rated)Dimensions·.···(361罚安日188m02翻2Weight8.5 kg(18.7 Ibs.)net9.7 kg (21.4 Ibs.)packedSansui.<5C-5330>8.7 kg (19.2 Ibs.)net10.3 kg (22.7 Ibs.)packedSANSUI ELECTRIC CO.,LTD.Design and specifications subject to changes without noticefor improvements.
