01-10-29；2:33PM;#63130UDC621.884.75:620.1August 1991Break mandrel blind rivets正7337Blindniete mit SollbruchdornSupersedes July 1985 edition.In keeping with current practice in standards published by the Interational Organization for Standardization (ISO).a comma has been used throughout as the decimal marker.Dimensions in mm1Scope and field of applicationThis standard specifies dimensions of,and requirements regarding material,design,strength and finish,as well as therelevant methods of test for,blind rivets of the self-plugging type.Such rivets consist of a rivet body and an integralmandrel,which breaks off on setting (break mandrer.for short).They are intended in particular for applications wherethe back side is not normally accessible after rivettingUse of biind rivets for automatic feed shall be the subject of agreement.Continued on pages 2 to 11176
