Elecraft KXPD3 Precision Keyer PaddlesRevision F,April 27,2017E740166Copyright 2017,Elecraft,Inc.,All Rights ReservedThe KXPD3 paddles are designed for use with the KX3 transceiver.They mount directly on the KX3 to providesmooth,stable and compact operation anywhere with the KX3 sitting flat or standing on its tilt feet.Each paddlefeatures fully adjustable contact spacing.SPOTCWT 4 PITCH 5NTCH32Figure 1.KXPD3 Paddles Mounted on KX3.Parts IncludedIncluded with your fully assembled KXPD3 paddles are the following wrenches and springs that you can use tocustomize the feel of your paddles.Full instructions for doing so are included on the following pages.KXPD3 Tension SpringsYour KXPD3 Paddles are supplied with a medium weight spring(E980240)installed.A firmer spring(E980218)and a lighter spring (E980239)are supplied (see Spring Replacement,pg 3).KXPD3 Wrench SetThe wrench set(E850522)includes one 0.035"hex wrench and one 0.050"hex wrench for adjusting thecontacts (see Contact Spacing Adjustment,pg 3).Also included is one 3/32"hex wrench required for changing the tension springs.Elecraft,Inc..www.elecraft.com.831-763-4211
