FT-1000MP-Mk5-Field_维修维护电器原理图手册_2002

VERTEX STANDARD CO..LTD.HF Transceiver4-8-8 Nakameguro,Meguro-Ku,Tokyo 153-8644,JapanVERTEX STANDARDUS Headquarters17210 Edwards Rd.,Cerritos,CA 90703,U.S.A.MARK-V FT-1000MPInternational Division8350 N.W.52nd Terrace,Suite 201,Miami,FL 33166,U.S.AYAESU EUROPE B.V.P.O.Box 75525,1118 ZN Schiphol,The NetherlandsTechnical SupplementYAESU UK LTD.Unit 12.Sun Valley Business Park,Winnall CloseWinchester,Hampshire,S023 OLB.U.K.VERTEX STANDARD HK LTD.Unit 5.20/F..Seaview Centre.139-141 Hoi Bun Road.2002 VERTEX STANDARD CO.,LTD.EHO13H90AKwun Tong,Kowloon,Hong Kong日0▣5日《日▣@1▣日日-@01口▣口This manual provides technical information necessary for servicing the Yaesu MARK-V FT-1000MP Field HF transceiver.It doesnot include information on installation and operation,which are described in the MARK-V FT-1000MP Field Operating Manual,pro-vided with each transceiver,or on MARK-V FT-1000MP Field accessories,which are described in manuals provided with each.The MARK-V FT-1000MP Field is carefully designed to allow the knowledgeable operator to make nearly all adjustments requiredfor various station conditions,modes and operator preferences simply from the controls on the panels,without opening the case of thetransceiver.The MARK-V FT-1000MP Field Operating Manual describes these adjustments,plus certain internal settings.Servicing this equipment requires expertise in handling surface mount chip components.Attempts by non-qualified persons to servicethis equipment may result in permanent damage not covered by warranty.For the major circuit boards,each side of the board is identifiedby the type of the majority of components installed on that side.In most cases one side has only chip components,and the other has eithera mixture of both chip and lead components(trimmers,coils,electrolytic capacitors,packaged ICs,etc.),or lead components only.While we believe the technical information in this manual is correct,Vertex Standard assumes no liability for damage that may occuras a result of typographical or other errors that may be present.Your cooperation in pointing out any inconsistencies in the technicalinformation would be appreciated.Vertex Standard reserves the right to make changes in this transceiver and the alignment procedures,inthe interest of technological improvement,without notification of the owners.YAESU
