离网逆变器MKSII5K操作使用手册

Appendix I:Parallel function1.IntroductionThis inverter can be used in parallel with two different operation modes.1.Parallel operation in single phase with up to 9 units.The supported maximum output powerand for 5KW is 45KW/45KVA.2.Maximum nine units work together to support three-phase equipment.Seven units support one phasemaximum.For 5KW,the supported maximum output power is 45KW/45KVA and one phase can be up to35KW/35KVA.NOTE:If this unit is bundled with share current cable and parallel cable,this inverter is default supportedparallel operation.You may skip section 3.If not,please purchase parallel kit and install this unit by followinginstruction from professional technical personnel in local dealer.2.Package ContentsIn parallel kit,you will find the following items in the package:Parallel boardParallel communication cableCurrent sharing cable3.Parallel board installationStep 1:Remove wire cover by unscrewing all screws.Step 2:Remove communication board by unscrewing two screws as below chart.
