编号65：建伍KENWOOD-NX-740(H)(V)_B5B-7126-00维修图纸手册

KENWOODSERVICE MANUALVHF DIGITAL TRANSCEIVERNX-740H,NX-740HV),NX-740S但回周KENWOODACC.SPNote:Lead free solder used in the board(material:Sn,Ag,In,Bi,melting point:227 Centigrade)TABLE OF CONTENTS1PRECAUTION.........................................................................142SPECIFICSERVICEINSTRUCTIONS......................................................1-43DISASSEMBLY ......................................................................1-214ADJUSTMENT......….1-235TROUBLESHOOTING.................................................................1-29LFThis product complies with the RoHS directive for the European market.This product uses Lead Free solderB5B-7126-00COPYRIGHT 2014 JVC KENWOOD CorporationNo.RA0102014/5
