MDS-LSA1SERVICE MANUALAEP ModelUK Model回·回回US and foreign patents licensed from Dolby LaboratoriesModel Name Using Similar MechanismNEWLicensing Corporation.MD Mechanism TypeMDM-7X2BOptical Pick-up TypeKMS-262A/1NSPECIFICATIONSSystemMiniDisc digital audio systemInputs/outputsDiscMiniDisci.LNK S200Jack type:4-pins to 4-pinsLaserSemiconductor laser(饩=780nm）Emission duration:continuousGeneralLaser outputLess than 44.6 uwPower requirements230 V AC.50/60 HzThis output is the value measuredPower consumption18Wat a distance of 200 mm from theDimensions (approx.)430 x 70 x 315 mm (w/h/d)incl.objective lens surface on the Opticalprojecting parts and controlsPick-up Block with 7mm aperture.Mass (approx.)44kgLaser diodeMaterial:GaAlAsRevolutions (CLV)400 pm to 900 rpmSupplied accessoriesError comectionACIRC (Advanced Cross Interleavei.LINK connecting cable (1)Reed Solomon Code)Remote commander (remote)(1)Sampling frequency44.1 kHzCodingATRAC (Adaptive TRansfomDesign and specifications are subject to change without notice.Acoustic Coding)/ATRAC3Modulation systemEFM (Eight-to-Fourteen Modulation)Number of channels2 stereo channelsFrequency response5to20.000Hh03dBSignal-to-noise ratioOver 100 dB during playbackWow and flutterBelow measurable limitMINIDISC DECKSONY
