Akai-AMA335-int-维修说明书手册含电器原理图

AKAI SERVICE MANUALAKAIAM-A335HGH FDEUTY SOUND启STEREO INTEGRATED AMPLIFIERMODEL AM-A335MODEL AM-A535SPECIFICATIONSPower output(DIN 1 kHz)FiltersAM-A335..35W+35WHigh................7 kHz,-6 dB/octAM-A53560W+60WSubsonic...18 Hz,-6 dB/octMusic power outputPower requirements…220V,50 Hz for Europe exceptAM-A335.:160WUK.AM-A535.270W240V,50 Hz for UK andS/N(IHF-A)Australia.110V/120V/220V/240VPhono (MM)................75 dB50/60 Hz convertible for otherTuner etc.100dBcountries.Residual noise .......0.4 mVDimensions...............425(W)×130(H)×270(D)mmChannel separation(16.7×5.1×10.6 inches)(1 kHz).....60dBDamping factorWeightAM-A335.8.0kg(17.61bs)(1 kHz,8 ohms)......35AM-A53519e年gne1ge年1月9.0kg(19.81bs)Required speaker impedanceA or B.......................4 ohms to 16 ohmsA and B..8 ohms to 16 ohmsInput sensitivity/ImpedancePhono (MM)...............3 mV/47 kohmsTuner,etc ...............150 mV/47 kohmsPhono max.input level(1 kHz)......................100 mVStandard accessoriesOperator's manual ...........For improvement purposes,specifications and design are subject to change without notice.
