西门子温度传感器FT-TP100

SIEMENS济南工达孔功24小时为您服务！www.cngdkj.com电话：18653198028QQ:1319331276Immersion temperature senfor HVAC systems西门们子全国最大合作伙伴！Immersion temperature sensor for heating,ventilation and air conditioningsystemsFor use with controllers with Pt100 sensor inputsIn conjunction with MULTIREG and INTEGRAL RS.UseThe FT-TP/...immersion temperature sensors can be used in pipe systems for HVACsystems.They are suitable for high accuracy temperature measurement over a widerange with controllers equipped with a Pt100 sensor input,e.g.controllers from theMULTIREG and INTEGRAL RS ranges.Type summary2 types are available,distinguished only by the length of the probe.FT-TP/100Immersion temperature sensor length 100 mmFT-TP/400Immersion temperature sensorlength 400 mmOrderingWhen placing an order,please specify the quantity,product description and type code.Example:1 immersion temperature sensor FT-TP/400Technical designThe Pt100 temperature sensor is fitted with a platinium measuring element with apositive temperature coefficient(PTC).The measured-signal/temperature relationship islinear.See data sheet 1714 for technical information on the Pt100 sensor element.The sensor FT-TP/...comprises a probe with a connecting head and the inserted Pt100element.To improve the response time,the end of the sensor probe is narrowed.Thecable is connected via a PG16 cable gland.Mounting notesMounting instructions are enclosed with the sensor(Ref.35224).Where possible the immersionsensor should be mounted in apipe bend with the sensor probeagainst the direction of flow.Itshould be located in a positionwhere the medium is well mixedSiemens Building TechnologiesCA1N1797E/12.2001HVAC Products1/2
