Programmable Temperature ControllerMTC-48-P/MTC-49-P/MTC-72-P/MTC-96-PUser manualDimensionsPlease read this manual carefully and keep this manual for future打100ET101FT4DD/FT500use(unit:mm)(unit:mm)General SpecificationsMTC-P series programmable temperature controller,4 digits LED display,withbar graphic display,0.2%accuracy,0.1 resolution for thermocouple and Pt100input signal,0.001 resolution for analong input signal,auto/manual controlbumpless transferMaximum 4 different programs,each program with 8 segments,4 program canbe linked together as 1 program with 32 segmentsMaximum output power is configurable for each segmentSystem time unit is switchable bewtee hour,minute and secondEasy monitoring on current runing segment and program excution time periodThe program can start from process value or from 02The program can be triggered or terminated by front key or start runningautomatically after power on and controller has the power failure restore functior望When program finished,controller can repeat the preset program again orstop operating completelyGuaranteed soak functionsegment ending alarmx.program ending alarm,program running alarmsegment ending alarm delay function里RS-485 optional,master/slave communicaiton mode optionalPlease make sure the wiring is correct before power on,the wiring diagram ison the size of the controller for easy reference duing the wiring,make sure youare clear on the output type whether it is Relay,SSR drive or 4-20mAController can switch freely between thermocouple or RTD input signalsfor analog inputs,need to specify before orderThe factory default control action is OUT1 for reverse control(heating)customer can set OUT1 as direct control(cooling)Factory default control mode is P.I.D modeWhen I=0,d=0,the control mode set as time proportional mode,proportaionalvalue is rSt1,control cycle is Cyt1,the output decrease when rSt1 decreaseunder heating mode the output increase when rSt1 decrease under coolingcontrol mode
