AV RECEIVERRX-V461/HTR-6040/RX-V461DABSERVICE MANUALFor T,B,G and E modelsThis service manual is the RX-V461/HTR-6040/RX-V461DAB (T,B,G and E models).For the RX-V461/HTR-6040/DSP-AX461 (U,C,R,K,A,L and J models)service manual,please refer to thefollowing service manual:RX-V461/HTR-6040/DSP-AX461 (U,C,R,K,A,L and J models):101041IMPORTANT NOTICEThis manual has been provided for the use of authorizd YAMAHA Retailers and their service personnel.It has been assumed that basic service procedures inherent to the industry,and more specifically YAMAHA Products,are alreadyknown and understood by the users,and have therefore not been restated.WARNING:Failure to follow appropriate service and safety procedures when servicing this product may result in personalinjury,destruction of expensive components,and failure of the product to perform as specified.For these reasons,we advise all YAMAHA product owners that any service required should be performed by an authorizedYAMAHA Retailer or the appointed service representative.IMPORTANT:The presentation or sale of this manual toany individualor fim does not constitute authorization,certification orrecognition of any applicable technical capabilities,or establish a principle-agent relationship of any form.The data provided is believed to beure ad applicable to the unit(s)indicated on the cover.The research,engineering.adservice departments of YAMAHA are continually striving to improve YAMAHA products.Modifications are,therefore,inev itableand specifications are subject to change without notice or obligation to retrofit.Should any discrepancy appear to ex ist,pleasecontact the distributor's Service Division.WARNING:Static discharges can destroy expensive components.Discharge any static electricity your body may haveaccumulated by grounding yourself to the ground buss in the unit (heavy gauge black wires connect to this buss).IMPORTANT:Turn the unit OFF during disassembly and part replacement.Recheck all work before you apply power to the unit.■CONTENTSTO SERVICE PERSONNELDISPLAY DATA…30-31FRONT PANELS.....3IC DATA....…32-47REAR PANELS.4-5BLOCK DIAGRAMS49-50REMOTE CONTROL PANELS.6PIN CONNECTION DIAGRAMS51RX-V461DSPECIFICATIONS.........7-9PRINTED CIRCUIT BOARDS52-66RX-V461/HTR-6040/INTERNAL VIEW10SCHEMATIC DIAGRAMS67-80DISASSEMBLY PROCEDURES..10-12REPLACEMENT PARTS LIST.....81-91UPDATING FIRMWARE13-14REMOTE CONTROL........92-93SELF DIAGNOSIS FUNCTION (DIAG)................15-29Advanced setup .......94二D竹一上入了二1了儿体、工3マ一夕语定再生毓卷使用儿TL'米寸This Service Manual uses recycled paper.米YAMAHA1010482007 YAMAHA CORPORATION All rights reserved.This manual is copyighted by YAMAHA and may not be copiedorredistrbuted either in pint or electonically without permission.YAMAHA CORPORATIONP.O.Box 1,Hamamatsu,JapanDownloaded from www.Manualslib.com manuals search engine907.07
