SONY-TA-FE370-FE570

TA-FE370/FE570SERVICE MANUALAEP ModelUK ModelVer.1.22006.02Photo:TA-FE570SPECIFICATIONSAmplifier sectionGeneralDIN power outputSystemTA-FE570:110W+110WPower amplifier with all stages directly coupled(4 ohms at 1 kHz)Preamplifier:Low-noise,equalizerTA-FE37070W+70wamplifier(4 ohms at 1 kHz)Power requirements230 VAC.50/60 Hz±l.0dB190WTUNER,CD,AUX,TAPEI/DAT,TAPE2/MD:TA-FE370:160w7Hz-70 kHz dB06W(In standby mode）S/N(network A)PHONO:80dBDimensions (approx.)(w/h/d)TUNER,CD,AUX,TAPEI/DAT,TAPE2/MD:430x135x310mm106dBincl.projecting parts andcontrolsRt2trolageimpeda8,200mV,1 kilohmMass(approx.)PHONES:5 mW (at 8 ohms)TA-FE570:6.5kgTA-FE370:5.5kgSpeakers impedance 4-16 ohmsSupplied accessoriesDamping factor80(8 ohms,1 kHz)Remote commander (remote)RM-S325 (1)Sony batteries R6(size-AA)(2)INTEGRATED STEREO AMPLIFIER9-873-838-13Sony Corporation2006B05-1Home Audio Division©2006.02Published by Sony Techno Create CorporationSONY
