AIWA-00391AIWAS/M Code No.88-033 DATE OF ISSUE 6/1988-1XK-009SERVICEMANUALSTEREO CASSETTE DECKBASIC TAPE MECHANISM:a-6◆TYPE.H,C,E,K,K1,ZSPECIFICATIONSTypeStereo cassette tape deckPlayback headPC-OCC coil pure amorphous headTrack format4 tracks,2 channelsRecording headPC-OCC coil pure amorphous headPower supplyXK-009E,ZErase headDouble-gap sendust headAC220V,5060HzInputsREC/LINE IN,CD/DAT DIRECT INXK-009K,K1maximum input sensitivity:50 mVAC240V.5060Hz47kXK-009COutputsPLAY/LINE OUT standard outputAC 120 V,60 Hzlevel:530 mV (0 VU);suitable loadXK-009Himpedance:over 47 kn.AC120V/220V240VPHONES:1.5 mW (8)switchable,50/60 HzDimensions469W0×136(H)×432.7(D)mmPowerWeight102kgconsumptionXK-009E,K,K1,Z,C33WXK-009H30WFrequencyresponseMETAL tape:20-22,000H2CrO2 tape:20=21,000HzDesign and specifications are subject to change withoutNORMAL tape:20-20,000Hznotice.Signal-to-noiseNoise reduction systen nanufactured under license fromratio95 dB(METAL tape dbx NR ON)Dolby Laboratories Licensing Corporation.Wow and flutter0.035%(According to DIN 45500)Dolby and theo symbol are trademarks of Dolby Labo-0.018%WRMS)Tape speed4.8 cm/sec.(1-7/8 ips)ratories Licensing Corporation.Recording system AC bias(frequency 105 kHz)Erase systemAC erase"dbx is a trademark owned and registered by dbx"MotorSystem servomotor (for thecapstan)x 1DC motor (for tape take-up duringplayback/recording)x 1DC motor (for F FWD/REW)x 1AIWA Co..Ltd.Tokyo Japan
