Nov.2002M-1000M-1▣▣▣SERVICE NOTES24bit/96kHz 56bit Internal ProcessingIssued by RJAI▣CH▣IGITAL LINE MIXERTABLE OF CONTENTSSPECIFICATIONS......2TEST MODE0.12LOCATION OF CONTROLS PARTS LIST.4BLOCK DIAGRAM......16LOCATION OF CONTROLS.4CIRCUIT BOARD (MAIN/PANEL/POWER).........18EXPLODED VIEW PARTS LIST.........6CIRCUIT BOARD (MAIN/PANEL/POWER)..........20EXPLODED VIEW..CIRCUIT DIAGRAM (MAIN 1/3)............PARTS LIST..........8CIRCUIT DIAGRAM(MAIN 2/3)........24CHECKING THE VERSION NUMBER...12CIRCUIT DIAGRAM (MAIN 3/3)......26RESTORING THE FACTORY SETTINGS.................12CIRCUIT DIAGRAM (PANEL/POWER)................28Roland M-iCopyright 2002 ROLAND CORPORATIONAll rights reserved.No part of this publication may be reproduced in any form without the written permissionof ROLAND CORPORATION.Roland17058116E0Printed in Japan(0800)(AS)
