☑SensorexPRODUCT INSTRUCTION SHEETIn-line pH Electrode Fitting with ATC for S222C/CD(Model FC75TC)Product InstructionsDescription of PartsG.1FC75TC consists of:3/4"mounting gland(FC75P)used withModel S222C/CD Electrode,modified SCH80 PVC tee,cap andcable with temperature sensor in 1/4"nipple.>10degMechanical InstallationUsing Pipe Thread Sealing Tape or other pipe thread sealanton the connecting pipe threads and taking care to not over-ITEE INLET ORtighten plastic threads(particularly when screwing male metalOUTLETpipe into female plastic fittings)proceed as follows:1)Tee Installation:Install modified tee in-line makingF1G.2sure to position tee at least 10 degrees above thehorizontal position.Refer to FIG.1.2)ATC Installation:Install the cable assembly's 1/4"nipple into the 1/4"NPT hole on the underside ofthe tee.Refer to FIG.2.Gland InstallationUsing Pipe Thread Sealing Tape or other pipe thread sealantinstall the gland's 3/4"NPT thread into the top of the tee.Use Pipe Thread SealingDo not overtighten.Refer to FIG.3.Tape to seal threadsElectrode Installation15.3To install the S222C/CD electrode,loosen nut on top of glandby rotating counterclockwise.Slip electrode through hole innut until desired insertion depth is reached.Once installed atthe correct depth,tighten nut by turning clockwise(hand tighten only)Refer to FIG.4Cable ConsiderationsUse Pipe ThreadThe gray plastic cap with the recessed BNC connector is fittedSealing Tapeonto the electrode's connector.The exposed cable should beto seal threadssecured with supports to prevent cable sway.The cable assembly mounts onto the electrode by a 1/4 turnwhich locks together the BNC connector on top of the S222C/CD electrode into the recessed BNC inside the cable's graycap.It is important that the cable assembly be locked intoposition.Parts covered by this product data sheet include:FC75TC,S222CDPage 1 of 2Form InstallFC75TC [Rev:2012-05-16]2011 Sensorex Corportion
