松下H-FS045200维修手册

ORDER NO.DSC0810047CEB26Service ManualInterchangeable Lens for Digital CameraMEGAH-FS045200E0.l.8GWMICROH-FS045200GKH-FS045200PPVol.1SpecificationsINTERCHANGEABLE LENS FOR DIGITAL CAMERA"LUMIX G VARIO 45-200 mm/F4.0-5.6/MEGA O.I.S."Focal lengthf=45 mm to 200 mm(35 mm film camera equivalent:90 mm to 400 mm)Aperture type7 leaf shutters/iris diaphragm/circular diaphragmAperture rangeF4.0 (Wide)to F5.6 (Tele)Minimum aperture valueF22■Lens construction16 elements in 13 groups (no aspherical lenses)In focus distance1.0 m(3.28 feet)to(from the focus distance reference line)Maximum image magnification0.19x (35 mm film camera equivalent:0.38x)Optical image stabilizerAvailableMount"Micro Four Thirds Mount"Angle of view27°Nide)to6.2°(Tele)Filter diameter52 mm(2.05 inch)Max.diameter70mm(2.76inch】Overall lengthApprox.100 mm (3.94 inch)(from the tip of the lens to the base side of the lens mount)Mass(Weight)Approx.380 g(13.4 oz)AWARNINGThis service information is designed for experienced repair technicians only and is not designed for use by the general public.It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.Products powered by electricity should be serviced or repaired only by experienced professional technicians.Any attempt to serviceor repair the product or products dealt with in this service information by anyone else could result in serious injury or death.PanasonicPanasonic Corporation 2008.Unauthorizedcopying and distribution is a violation of law.
