S/M Code No.89-070 DATE OF ISSUE 9/1989-TAIWAXA-005SERVIC旺0■0MANUALSTEREO INTEGRATED AMPLIFIER·TYPE.H,E,K,ZSPECIFICATIONSCommonPreamplifierPower requirementsXA-005E,ZS/N ratioIHF A curve short circuited220V,50HzPHONO (MM)XA005K85 dB(5 mV INPUT)240V.50HzTUNER,DAT,VCR (AUX).TAPEXA-005H100dB120V220V/240VInput jacks(switchable),50/60 Hz(Sensltlvity/nput Impedance)Power consumptionXA-0O5E,K,ZPHONO (MM)350W2.5 mV/47 kohmsXA-005HTUNER,DAT,VCR(AUX),TAPE125W150 mV/47 kohmsCDPower amplifier150 mV/47 kohmsEffective output power 70 W+70 WPHONO overload level 85 mV (MM)(4 ohms,T.H.D.0.9%,1 kHz)[1 kHz,THD 0.01%]50W+50WOutput jacks(8 ohms,T.H.D.0.9%,1 kHz)(Level/output Impedance)Total harmonlc distortionTAPE 150 mV/47 kohms0.05%Headphones 8-32 ohms(20 Hz-20 kHz.40 W,8 ohms)Speakers 4-16 ohmsOutput bandwidth20 Hz-20 kHz(A+B:8-16 ohms)(less than 0.05%)RIAA deviation±0.5dB30Hz-15kH[Both channels driven,8 ohms]Frequency response5Hz-100kHz(+0.5/-3dB)Dlmenslons430WM×140H)×320D)mmWelght7 kgDesign and specifications are subject to change withoutnotice.AIWA Co.,Ltd.Tokyo JapanPrinted in Japan
