ABioHarness 3S Y S T E M SQUICK REFERENCEBy HoneywellIMPORTANT!Follow all instructions here before operating the BioHarness 3.Make sure your strap isthe correct size before using it (available in two sizes,Small XS-M or Large M-XL).For more details,refer to the BioHarness 3,RAELink3 (or RAELink3 Z1,which has the same functions),and ProRAEGuardian User's Guides or Quick References.The BioHarness 3 measures the following parameters:SensorUnitRangeDefinitionBreath RateBth/m (breaths per minute)0to120Heart RateBts/m (beats per minute)0to240ActivityVMU (Vector Magnitude±16<0.2 Low ActivityUnits)0.8 Walking/Jogging>0.8 RunningPostureDegrees0to1800=Vertical90 Horizontal180 InvertedTemperatureDegrees F or C50°to140°F10°to60°COperation1.Moisten the gray sensor pads on the back of the strap with water2.Snap the BioHarness Echo Module onto the BioHamess 3 by clicking the bottom in first and then the top.3.Power on the BioHarness Echo Module by pressing the button in the center until all four LEDs flash.4.Link the BioHarness Echo Module to the RAELink3Note:It links automatically after the initial Bluetooth pairing.5.Attach the shoulder strap with Velcro in the back and fit the clasp to the loop in the front,andthen do the same with the clasp and loop in the front.4④Note:BioHarness Echo Module should be under the left armpit when properly positioned.
