AU-D11IlSERVICE MANUAL·SPECIFICATIONSPower outputMin.RMS,both channels driven,from 10to 20,000 Hz,withno more than 0.0028%total harmonic distortion.INTEGRATED AMPLIFIER130 watts per channel into 8 ohms.Load impedance.........8 ohmsTotal harmonic distortionSANSUI AU-D11I...less than 0.0028%at or below rated min.RMS poweroutputIntermodulation distortion(60 Hz:7 kHz=4:1 SMPTE method)..........less than 0.0028%at ratedpower outputFrequency response (at 1 watt)Overall (from AUX).....DC to 300,000 Hz,+0 dB-3.0dBRIAA curve deviation (DISC-MM,20 Hz to 20 kHz).+0.2dB,-0.2dBInput sensitivity and impedance(at 1 kHz)DISC-MC-HIGH........250 V/40 ohmsDISC-MC-LOW............70 uV/3.2 ohms(Max.input capability (LOW):25 mV at 1 kHz,lessthan 0.01%total harmonic distortion)DISC-MM.......2.5 mV/47 kilohms(Max.input capability:200 mV at 1 kHz,less than0.01%total harmonic distortion)DISC-DA......…150mV/47 kilohmsAUX,TUNER,TAPE PLAY-1,2..150 mV/47 kilohmsOutput level (1,000 Hz)CAUTIONTAPE REC-1,2............150 mV into 47 kilohms1.Parts identified by the symbol on the schematicSignal to noise ratio(short-circuit,A-network)DISC-MC.diagram and the parts list are critical for safety.80dBDISC-MM..90 dBUse only replacement parts that have criticalAUX,TUNER,TAPE PLAY-1,2characteristics recommended by the manufacturer..110dBControls and Filter2.Make leakage-current or resistance measurementsBAS5±10dBat50Hzto determine that exposed parts are acceptably in-Tone selector..125Hz,250HzTREBLE...sulated from the supply circuit before returning the.±10dBat10kHzTone selector........3 kHz,6 kHzappliance to the customer.SUBSONIC-3 dB at 16 Hz (6 dB/oct)MUTING-20dBLOUDNESS+8 dB at 50 Hz(VOLUME:-30 dB+6 dB at 10kHzposition)Power requirementsPower voltage...120/220/240V(50/60Hz)For U.S.A.Canada.120V(60HzPower consumption....470 watts 560 VA Rated700 watts MaximumDimensions..........466mm(18-3/8)W161mm(6-3/8)H431mm(17)DWeight.17 kg (37.4 Ibs)net19 kg (41.8 Ibs)packedDfiic to chnge h ice ormSansuiSANSUI ELECTRIC CO.,LTD.
